10-Hole Hub Pilot | 285.75mm Bolt Circle | Steer, Lift, or Pusher Axle
Upgrade your truck or bus with the Northstar 22.5 x 9.00 Satin Black Forged Aluminum Wheel, designed for steer, lift, and pusher axle applications. Built for strength, durability, and modern style, this wheel features a sleek satin black finish that delivers a bold look while standing up to the toughest road conditions.
With its hub-piloted 10-hole design, 285.75mm bolt circle, and 220mm center bore, the Northstar wheel ensures precise fitment and balanced performance. Engineered to handle heavy-duty commercial applications, it supports a maximum load capacity of 9,900 lbs at 130 PSI.
Size: 22.5” x 9.00
Finish: Satin Black (Front)
Position: Steer, Lift, or Pusher Axle
Bolt Pattern: 10-Hole Hub Pilot, 285.75mm Bolt Circle
Hub Bore: 220mm
Offset: 7.00”
Bolt Hole Diameter: 26mm
Max Load: 9,900 lbs @ 130 PSI
Warranty: 5 Years
315/80R22.5
295/60R22.5
12R22.5
Alcoa 89U64x
Accuride 29730, 41730
Large Buses & Motor Coaches
Heavy-Duty Truck Steer Axles
Lift Axles & Pusher Axles
Forged Aluminum Construction – Combines maximum strength with significant weight savings over steel.
Premium Satin Black Finish – Provides a bold, corrosion-resistant appearance.
Heavy-Duty Capacity – Rated for up to 9,900 lbs at 130 PSI, perfect for commercial and vocational fleets.
Precision Fitment – Hub-piloted 10-hole design ensures reliable mounting and performance.
Warranty Protected – Backed by a 5-year manufacturer warranty.
The Northstar 22.5 x 9.00 Satin Black Forged Aluminum Wheel delivers strength, efficiency, and aggressive styling—making it the ideal upgrade for buses, motor coaches, and Class 8 trucks running steer, lift, or pusher axle applications.
