DynaTrac MA400 MIXED USE MOUNTED ON 22.5 NORTHSTAR RAM 4500/5500 10X225MM (2012-Present)

Northstar
325670D-MA400
Out of stock
Wheel & Tire Assemblies
DynaTrac MA400 MIXED USE MOUNTED ON 22.5 NORTHSTAR RAM 4500/5500 10X225MM (2012-Present)
DynaTrac MA400 MIXED USE MOUNTED ON 22.5 NORTHSTAR RAM 4500/5500 10X225MM (2012-Present)
Click to zoom in
  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    Mounting, Balancing

  • Free Delivery

    Fast shipping on all US orders*

Step up to a set of 22.5” Direct Bolt On high polished aluminum wheels (10x225). Fits Dodge RAM 4500 & 5500 (2012-Present). Dynatrac mixed use tread tires come mounted and balanced. Free Shipping!

DynaTrac MA400 MIXED USE MOUNTED ON 22.5 NORTHSTAR RAM 4500/5500 10X225MM (2012-Present)

Northstar
325670D-MA400
Out of stock
Wheel & Tire Assemblies
Step up to a set of 22.5” Direct Bolt On high polished aluminum wheels (10x225). Fits Dodge RAM 4500 & 5500 (2012-Present). Dynatrac mixed use tread tires come mounted and balanced. Free Shipping!
$5,199.00


customers are viewing this product

DynaTrac MA400 MIXED USE MOUNTED ON 22.5 NORTHSTAR RAM 4500/5500 10X225MM (2012-Present)

WHEEL SPECS


GENERAL SPECS

Material
Aluminum / Steel
Finish
Mirror Polish / Painted Black
Mounting Set Up
Hub-Piloted (Two-Piece Flange Nut) Dual
Wheel Size
22.5 x 6.75
Bolt Pattern (PCD)
10 x 225mm
Hub Bore Diameter
170.1mm
Hand/Vent Holes
10 @ 2.6" / 5 @ 2.36" (oval)
Wheel Offset
5.87" / 5.67"
Backspacing
9.25" / 9.20"
Disc Thickness
.80" / .43"
Weight
47 lbs. / 75 lbs.
Max Load
6170 lbs. / 5000 lbs.
Valve Stem
TR544D

Kit Includes:

6 - DynaTrac M400 Mixed Use Tires
4 - Aluminum Wheels Polished Both Sides
2 - Steel Inner Dual Wheels  (steels my be white or black)
2 - Front ABS Chrome Plastic Hub/Lug Nut Covers (Emblem Optional)
2 - Rear ABS Chrome Plastic Hub/Lug Nut Covers (Emblem Optional)
40 - 22mm Hex Nuts M14 x 1.5 (OEN29-14150)

Tire Specs:

Quantity: 6 DynaTrac M400 Mixed Use Tires
Size: 255/70R22.5
Ply: 16
Load Range: H
Max Load Single/Dual: 5510@120 psi/5070@120 psi
Overall Diameter: 36.64"
Tread Depth: 18/32"
Weight: 82 lbs

Aluminum Wheel Specs

Quantity: 4 Northstar Wheels
Finish: High Polished Aluminum
Wheel Size: 22.5" x 6.75"
Bolt Pattern: 10-Hole 225mm
Hub Bore: 170.1mm
Hand Holes: 10
Wheel Offset: 5.98”
Weight: N/A
Max Load: 3630 lbs
Mounting Set Up: Hub Pilot Dual-Mounting
Valve Stem: TR545D

Steel Wheel Specs:

Quantity: 2 Jantsa Wheels
Finish: Black or White Steel
Wheel Size: 22.5" x 6.75"
Bolt Pattern: 10-Hole 225mm
Hub Bore: 170.1mm
Hand Holes: 5
Wheel Offset: 5.67”
Weight: 75 lbs
Max Load & Inflation: 5000 lbs
Mounting Set Up: Hub Pilot Dual-Mounting
Valve Stem: TR545D

Fits These Trucks:

2012 Dodge Ram 4500
2013 Dodge Ram 4500
2014 Dodge Ram 4500
2015 Dodge Ram 4500
2016 Dodge Ram 4500
2017 Dodge Ram 4500

2018 Dodge Ram 4500
2019 Dodge Ram 4500
2020 Dodge Ram 4500
2021 Dodge Ram 4500
2022 Dodge Ram 4500

2012 Dodge Ram 5500
2013 Dodge Ram 5500
2014 Dodge Ram 5500
2015 Dodge Ram 5500
2016 Dodge Ram 5500
2017 Dodge Ram 5500

2018 Dodge Ram 5500
2019 Dodge Ram 5500
2020 Dodge Ram 5500
2021 Dodge Ram 5500
2022 Dodge Ram 5500

Read More
Read Less

Free Ground Delivery

We strive to get all orders out same day, if ordered before 2:00pm EST. We offer Free Shipping on all items, and ship most items on FedEx Ground. With multiple warehouses across the country most items are a 2 day transit time.

Bulk Orders

On orders of 12 wheels or more, customers must have a commercial address for bulk discount, or be willing to pick up pallet at local terminal.

Express Orders

On FedEx Express orders, Orders must be in by 1:00pm EST to give express delivery driver the 4 Hour window they require. Prices for express are displayed at checkout.

International Orders

We are happy to ship to our international customers. Just follow the checkout process and shipping fees will display at checkout with no obligation to purchase.

Returns

There will be a 20% restock fee on all returned items. Inbound and outbound freight is non-refundable. If you received free inbound freight that charge will be deducted from your credit. Full Details



If you have any questions don't hesitate to call or text 800-830-4547
